Signal Processor (EXTECH 9811) |
|
Power Input/Output Channels |
Input 3CH with independent AC/DC Power measurement / Output 6CH with independent DC measurement |
|
Signal Output Relay Contact |
PASS, FAIL, TESTING:250V,2A maximum |
|
Remote Control |
Independent Left and Right with 4 Bit TTL Input and 3 Relay Contact( 250V,2A maximum) |
|
Input /Output Terminal |
Input: Three Port Selection 250VAC 15A maximum, Output: 40A maximum |
|
Input Measurement Board |
|
|
Range |
Resolution |
Accuracy |
|
AC Voltage, V |
00.00– 30.00 |
0.01V |
± (1% of reading + 1 count) |
|
0.0 – 300.0 |
0.1V |
± (1% of reading + 1 count) |
|
AC Current, A(RMS) |
0.0000 – 0.3500 |
0.0001A |
± (1% of reading + 5 counts) |
|
0.000 – 3.500 |
0.001A |
± (1% of reading + 5 counts) |
|
0.00 – 15.00 |
0.01A |
± (1% of reading + 2 counts) |
|
AC Current, A(Peak) |
0.00– 200.00 |
0.1A |
± (2% of reading + 4 counts) |
|
AC Power, W |
00.00 – 35.00 |
0.01W |
± (1% of reading + 5 counts) |
|
0.0– 350.0 |
0.1W |
± (1% of reading + 1 count) |
|
0– 4000 |
1W |
± (1% of reading + 1 count) |
|
Output Measurement Board |
|
RIPPLE & NOISE Bandwidth |
35~20MHZ |
|
Input Impedance |
AC coupled 50W |
|
Range 1, mVp-p (100 ~ 1M Hz ) |
0.0– 300.0mV |
0.1mV |
±(2% of Reading + 2% of F.S.) |
|
Range 2, mVp-p (100 ~ 1M Hz ) |
0 – 3000mV |
1mV |
±(2% of Reading + 2% of F.S.) |
|
Range 1, mVp-p (<100HZ/ >1MHZ ) |
0.0– 300.0mV |
0.1mV |
-3dB - ( 2% of Reading + 2% of F.S.) ~
( 2% of Reading + 2% of F.S.) |
|
Range 2, mVp-p (<100HZ/ >1MHZ ) |
0 – 3000mV |
1mV |
-3dB - ( 2% of Reading + 2.5% of F.S.) ~ ( 2% of Reading + 2.5% of F.S.) |
|
Overshoot |
|
Range 1, V |
0.00 – 35.00 |
0.01V |
± (1% of reading + 0.2% of F.S) |
|
Range 2, V |
30.0 – 200.0 |
0.1V |
± (1% of reading + 0.2% of F.S) |
|
DC Current Measurement |
|
Range 1 ,mA |
0.000 –3.000 |
0.001mA |
±(0.3% of reading + 0.2% of F.S) |
|
Range 2 ,mA |
0.00 –30.00 |
0.01mA |
±(0.3% of reading + 0.2% of F.S) |
|
Range 3 ,A *1 |
0.00– 30.00 |
0.01A |
± (0.5% of reading + 0.2% of F.S) |
|
Programmable Output Voltage |
|
DC Voltage , V(Max. 10mA) |
0.000-8.000 |
0.002V |
±(0.3% of reading + 2 counts) |
|
External DC Voltage Measurement |
|
DC Voltage , V |
0.000-8.000 |
0.002V |
±(0.3% of reading + 2 counts) |
|
Short Current Measurement |
|
DC Current ,A |
0.0– 200.0 |
0.1A |
± (2% of reading + 4 counts) |
|
Timing Analyzer (EXTECH 9820) |
|
Input port |
300Vp-p Signal Differential Input |
|
Number of channels |
12 Channel (Include PG *1 , Sync *1) Isolated DC 500V |
|
Trigger level, two Range |
RN1 ± 0-20V , RN2 ±0-200V |
|
Trigger level, two Accuracy |
±1.0% + 2 counts |
|
Measurement Timer, mS |
Range |
Resolution |
Accuracy |
|
|
0.0~9999.9 |
100μs |
±(0.2% + 2 counts) |
|
Programmable AC Power Source (EXTECH 6110) |
|
MODEL 6110 |
1KVA/0-300V/Max. 25.2A |
|
Power Rating |
1000VA |
|
Output Voltage,AC |
0-300V AutoRange |
|
Max AC output Current(RMS) |
4.2AHighVoltageRange / 8.4ALowVoltageRange |
|
Output Frequency |
Range: 45-500HZ, Resolution: 0.1HZ, Accuracy: ±0.01% of setting |
|
Harmonic Distortion |
THD<0.5% at 45-500Hz (Resistive Load) |
|
Load Regulation |
± (0.5% of output +0.5V) at Resistive Load |
|
Turn On Phase Angle |
0-360° Resolution: 1°, Accuracy: ±1°(45-65HZ) |
|
Electronic Load (3315A × 2) |
|
MODEL 3315A |
60V/15A/75W |
|
|
Range |
Resolution |
Accuracy |
|
CC MODE |
0-1.5A/0-15A |
0.375mA/3.75mA |
±(0.2% of Setting + range) |
|
CR MODE |
4-16KΩ/0.2-4Ω |
0.0625mS/1mΩ |
±(0.2% of Setting + range) |
|
CV MODE |
0-60V |
0.015V |
±(0.1% of Setting + range) |
|
DYNAMIC MODE |
THigh/TLow 50μSec TO 9.999Sec |
|
OPERATION |
Slew Rate 10-62.5mA/μSec, 10mA-625mA/μSec. |
|
LoadON Voltage |
0-3V ,Adjustments are made through the Load module VR1 resistance , Output voltage default is 1V. |
|
Protection |
OCP, OPP, OVP, OTP |
|
Programmable DC Power Supply(PPS-2017) OVP |
|
MODEL 2017 |
60V/3A/180W |
|
|
Range |
Resolution |
Accuracy |
|
Output Voltage,DC |
0-60V |
20mV |
0.05% ± 2 LSB |
|
Current,DC |
0-3.0A |
1mA |
0.15% ± 5 LSB |
|
System Controller |
|
Controller |
IPC P4 -2.4GHZ with DDR 256MB,CD-ROM 52 SPEED, FDD 1.44MB,HDD 40GB |
|
Operational Environment |
Windows XP with Excel XP |
|
Display monitor |
15" TFT LCD Display |
|
Interational Board |
NI GPIB Card (PCI) |
|
System General Specifications |
|
Dimension and Weight |
35U Equipment Rack, 180Kg |
|
Electrical |
230 VAC±10% , 50/60Hz 15A Single Phase |
|
Environment |
40℃,RH 20~80% |
|
Option maximum Input 4CH/Output 8CH. Product specifications are subject to change without notice. |
|
*1 Sofware measurement are not available. |
